Active Directional Reader - 528 is a long-range RFID reader designed for real-time tracking of active RFID tags. It offers directional detection and a range of up to 100 meters, making it ideal for personnel tracking, asset monitoring, and vehicle access systems.
Active Directional Reader - 528 is a high-performance RFID reader that works with active RFID tags to enable real-time, directional tracking. It is engineered for long-range detection (up to 80–100 meters) and supports directional reading to determine tag movement in or out of a zone.
With support for 2.4GHz active RFID technology, the reader is ideal for secure tracking of personnel, assets, or vehicles in high-security environments. It includes multiple communication options such as RS485, TCP/IP, and Wiegand, and is built with industrial-grade components for dependable performance in both indoor and outdoor applications.
PERFORMANCE
|
Product Dimension |
315mm x 200mm x 110mm |
|||
|
Weight |
1.6 Kg |
|||
|
Power Supply |
DC 5V input |
|||
|
Power Consumption |
300mW |
|||
|
Power Isolation |
1KV (Except Ethernet Data, I/O port) |
|||
|
Tag Protocol |
Private Protocol |
|||
|
Indicator |
Buzzer |
|||
|
Tag Operation Mode |
Compatible with active and passive operating mode tags |
|||
|
Reading Range |
0-150m (depend on the tag power output) |
|||
|
Reading Range |
0-80 m (depend on the Tag Power Output) |
|||
|
Identification Speed |
200pcs/s (Tag ID) |
|||
|
Anti-collision |
Identifying 300pcs tag at the same time |
|||
ENVIRONMENTAL SPECIFICATION
|
Temperature |
-40oC to +60oC (Operating), -60oC to +80oC (Storage) |
|
Humidity |
5% RH – 95% RH non condensing |
|
Protection Class |
IP 67 |
|
Shock Resistance |
10-500Hz, 100mm/15g, Triaxial |
RF PARAMETERS
|
Operating Frequency |
2.4 to 2.48 GHz |
|
Sensitivity |
-95dBm |
|
Communication Interfaces |
RS-232, 10/100M Adaptive Ethernet |
|
Expansion Interfaces |
RS-485 interface, Wiegand 26/34 interfaces |
|
I/O Port |
2- channel relays output, 2- channel trigger input |
|
Firmware Upgrade |
Yes |
|
SDP |
Provided DLL and Demonstration Software Source code to Facilitate |
