The ACR39U-H1 is a sleek, high-speed USB Type A smart card reader with a swivel design, ideal for secure authentication in e-Government, online banking, e-Payment, and digital signature applications.
The ACR39U-H1 (ACR39-H1) is a stylish and compact smart card reader from Advanced Card Systems Ltd. (ACS) that delivers high performance and portability. Featuring a swivel USB Type-A connector and a minimal footprint, it is ideal for users who need a reliable and mobile smart card reader solution.
Like others in the ACR39U family, the H1 version supports ISO 7816 Class A, B, and C smart cards (5V, 3V, 1.8V) and is compliant with PC/SC and CCID standards, ensuring plug-and-play compatibility across Windows®, macOS®, Linux®, and Android™ (via OTG) platforms.
Built to meet the stringent requirements of e-ID, e-Government, online banking, and secure login systems, the ACR39U-H1 provides reliable reading/writing of smart cards, supporting both T=0 and T=1 protocols.
Its unique flip/swivel USB design enhances usability and protects the connector when not in use, making it perfect for mobile professionals, remote workers, or field agents.
| Feature | Details |
|---|---|
| Model | ACR39U-H1 (also referred to as ACR39-H1) |
| Interface | USB 2.0 Full Speed Type-A, with swivel connector |
| Smart Card Support | ISO 7816 Class A, B, and C (5V, 3V, 1.8V) |
| Protocols Supported | T=0, T=1 |
| Data Transfer Rate | Up to 600 Kbps |
| Connector Type | Swivel USB Type-A |
| Smart Card Interface | Friction contact (min. 100,000 insertions) |
| Standards/Compliance | PC/SC, CCID, EMV Level 1, ISO 7816 |
| Operating System Support | Windows®, macOS®, Linux®, Android™ (with OTG support) |
| Certifications | CE, FCC, RoHS, EMV, ISO 7816 |
| Power Supply | USB bus-powered |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -25°C to 70°C |
| Dimensions | Approx. 65.0 mm × 20.0 mm × 10.0 mm |
