The FINGERPRINT iClock990 is an advanced biometric time attendance and access control terminal designed for efficient workforce management. It primarily uses fingerprint recognition technology to authenticate users and record attendance, ensuring secure and accurate tracking. The device supports a large capacity of fingerprint templates and transaction records, making it ideal for medium to large businesses.

The iClock990 boasts a high-speed fingerprint verification system, ensuring quick and precise identification. It includes a 3.5-inch TFT color screen, providing an intuitive interface for users. The device offers multiple communication options like TCP/IP, USB, and RS232/485, allowing flexible integration into different network environments. It also supports backup battery functionality and optional proximity card or password authentication, adding extra layers of security and convenience.

The iClock990 is designed to handle high-traffic environments and provides real-time data transfer, making it an effective solution for organizations that require robust, reliable attendance tracking and access control.

STORAGE CAPACITY

• Users : 40000
• Fingerprint Capacity : 40000
• Card Storage : 40000
• Transaction Capacity : 800000
• Card reader : Yes
• CPU : 32 bit Microprocessor

BIOMETRIC

• Fingerprint sensor : 500 DPI Optical sensor
• FAR : <=0.0001%
• FRR : <=1%
• Identification speed : <=1 sec
• Algorithm Ver :10

AUDIO & VISUAL

• Display : 3.5" color TFT
• LED Indicator : Green/Red
• Schedule Bell/Speaker : Mini Speaker

COMMUNICATION

• TCP/IP, USB, (Optional : Wifi, GPRS+ )
• Push data : Inbuilt
• Standard features : work code,SMS,DLST, Self service query, Status Switch

POWER & ENVIRONMENT

• Power Supply : DC 12V --- 3Amp
• Operating Temp : 0 °C - 45 °C
• Operating Humidity : 20% - 80%
• Dimension (in mm) : (L)210 x (W)157 x (H)40

ACCESS CONTROL

• Wiegand : In & Out both 26 or 34 bit (With or without site code)
• Relay : 12 V relay for lock EM lock, Bolt Lock or Strike lock
• Support Fire Alarm : Yes
• Door Sensor : Yes
• Anti Passback : Yes
• Door Bell : Yes

EXIT READERS

• Support exit readers : 101 HE, FR 1200, KR500E

OPTIONAL

• Battery : Yes
• Card Readers : Yes
• Communication : WiFi/GPRS
• Card Type : Mifare/HID Prox

COMPATIBILITY

• Compatible with Multi Door controllers via weigand
• External Speaker output available (Optional)
• External Bulb output available (Optional)
• Support External Printer (Optional)

COMPATIBLE SOFTWARE AND SDK

• ETimeTrackLite desktop & web
• SDK for desktop applications
• Web based Device Manager/ePush server using Push data, Helps developers & integrators
• Supports 3rd Party Payroll/HRMS/ERP and Other applications

MAJOR APPLICATIONS

• Time & Attendance , Canteen management, School attedance, Production Management, Gym & clubs
